Product DW2000-55-7F-H1141
Draw-Wire
Order number: 100000991- Measuring range up to 2000 mm
- M12
- Protection class: IP64
- Analog output, 4…20 mA
- Supply voltage 12…30 VDC
General data
| EAN | 4047101446388 |
| eCl@ss-Code (V5.1.4): | 27270790 -/- Sensor for length, path (not classified) |
| Customs tariff number | 9031804000 |
| Country of origin | DE |
| Weight | 385 g |
Technical Data
| Design | Draw Wire |
| Measuring range | 2000 mm [78.74 in] |
| Operating voltage | 12…30 VDC |
| Output function | Analog output |
| Current output | 4…20 mA |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Plastic |
| Ambient temperature | -20…+60 °C |
| Protection class | IP64 |
